Microtron MB 950 G 实验室混合器
实验室混合器 / 玻璃容器
实验室混合器，适用于可切割、干燥或液体样品的均质化和混合技术，含EU电源线（230 V）
分析和质量控制需要设备在样品制备方面具有灵活性且易于操作。这些混合器非常适合对可切割材料进行高强度混合、分散、均质化、乳化及绞切操作。操作简便、用户安全性高、效率出众，仅是这些混合器众多优势中的一部分。
Microtron MB 950 G – 实验室混合器 / 玻璃容器 – Kinematica AG
分析和质量控制需要设备在样品制备方面具有灵活性且易于操作。Kinematica 的这些混合器非常适合对可切割材料进行高强度混合、分散、均质化、乳化及绞切操作。操作简便、用户安全性高、效率出众，仅是这些混合器众多优势中的一部分。
Description
Analysis and quality control requires equipment that is flexible for preparing samples and easy to work with. These mixers are well suited for intense mixing, dispersing, homogenizing, emulsifying and mincing operations for cuttable materials. Simple handling, high user safety and efficiency are just a few advantages offered by these mixers.
Benefits
Ergonomics
– Smooth rotational speed adjustment with integrated on- and off switch
– Load compensated rotational speed adjustment
– Switching of mixing attachment and protection cover without tools
– Operation only possible with security cover and lid in place
– Variety of sample container designs
– Vibration dampening quick coupling
– Very quiet motor with integrated ventilation cooling
– Integrated load, heat and blockage protection
Results are crucial
– Production of very fine particle sizes in both liquid and dry mediums: precise analyses require homogeneous samples
– Efficient sample preparation: through high rotational speeds
– Flexibility: various sample volumes with different mixing attachments
– Handling: mounting of mixing attachment and protection cover without tools
– Longevity: a Swiss virtue
Technical Information
| Min. Volume (ml) | 125 |
| Max. Volume (ml) | 1000 |
| Power | 950 |
| Motor | Collector motor (Class H) / Gearless direct drive / Security system auto-off |
| Speed Range | 1000 – 14 000 rpm |
| Sound level | ca. 72 dB(A) at 14 000 rpm |
| Supply voltage | 230 V ± 10 %, 50Hz / 60Hz |
| Relative humidity (max.) | 80 % in storage / 80 % during operation |
| Operating temperature | 0 – 40 °C |
| Protection class acc. to DIN | IP 20 |
| ø / H (mm) | ø 190mm / 245 mm |
| Weight | 4.4 kg |
| EMC standards | EN 60335-1:1988, EN 60335-2-64:1993, EN 55014:1993, EN 55104:1995, EN 61000-3-2:1995, EN 61000-3-3:1995, EN 60335-2-64:1997 |
| Safety standard | Protection Class 1 according to EN 60335-1 |
Downloads
| Instruction Manual | English |  |
| Product brochure | English | > |
| Bedienungsanleitung | German | |
| Produktbroschüre | German | |
| Manuel d’instruction | French | |
| Brochure du produit | French | |
| Manuale di istruzioni | Italian | |
| Brochure del prodotto | Italian |  |
| Manual de Instrucciones | Spanish | |
| Catálogo del producto | Spanish | |
Description
Analysis and quality control requires equipment that is flexible for preparing samples and easy to work with. These mixers are well suited for intense mixing, dispersing, homogenizing, emulsifying and mincing operations for cuttable materials. Simple handling, high user safety and efficiency are just a few advantages offered by these mixers.
Benefits
Ergonomics
– Smooth rotational speed adjustment with integrated on- and off switch
– Load compensated rotational speed adjustment
– Switching of mixing attachment and protection cover without tools
– Operation only possible with security cover and lid in place
– Variety of sample container designs
– Vibration dampening quick coupling
– Very quiet motor with integrated ventilation cooling
– Integrated load, heat and blockage protection
Results are crucial
– Production of very fine particle sizes in both liquid and dry mediums: precise analyses require homogeneous samples
– Efficient sample preparation: through high rotational speeds
– Flexibility: various sample volumes with different mixing attachments
– Handling: mounting of mixing attachment and protection cover without tools
– Longevity: a Swiss virtue
Technical Information
| Min. Volume (ml) | 125 |
| Max. Volume (ml) | 1000 |
| Power | 950 |
| Motor | Collector motor (Class H) / Gearless direct drive / Security system auto-off |
| Speed Range | 1000 – 14 000 rpm |
| Sound level | ca. 72 dB(A) at 14 000 rpm |
| Supply voltage | 230 V ± 10 %, 50Hz / 60Hz |
| Relative humidity (max.) | 80 % in storage / 80 % during operation |
| Operating temperature | 0 – 40 °C |
| Protection class acc. to DIN | IP 20 |
| ø / H (mm) | ø 190mm / 245 mm |
| Weight | 4.4 kg |
| EMC standards | EN 60335-1:1988, EN 60335-2-64:1993, EN 55014:1993, EN 55104:1995, EN 61000-3-2:1995, EN 61000-3-3:1995, EN 60335-2-64:1997 |
| Safety standard | Protection Class 1 according to EN 60335-1 |
Downloads
| Instruction Manual | English | |
| Product brochure | English | > |
| Bedienungsanleitung | German | |
| Produktbroschüre | German | |
| Manuel d’instruction | French | |
| Brochure du produit | French | |
| Manuale di istruzioni | Italian | |
| Brochure del prodotto | Italian | |
| Manual de Instrucciones | Spanish | |
| Catálogo del producto | Spanish | |
